4.3" AHD CCTV camera tester analog camera audio UTP Cable Test

AHD camera tester CCTV tester monitor 12V1A output  Analog cameras and AHD cameras testing

Item specifics
AHD camera testing: video display
Audio testing: support
AHD cameras: 960p 720P D1
12V1A output: power supply for cameras
Analog camera testing: CVBS
4.3" LCD screen: 480RGBX272

Description

4.3" AHD camera tester CCTV tester monitor AHD and analog camera testing UTP cable test 12V1A output
Video test: Video System : NTSC/PAL Automatically recognize
Display screen: 4.3-inch LCD 480 * RGB * 272 (QVGA) resolution, 64K color
Screen adjustment: Video display brightness, contrast, color saturation adjustable, LCD backlight brigh tness adjustable
Video input / output: 1 channel BNC Video IN
HD AHD Test : SD signal Format
NTSC ,PAL: HD video signal
HD AHD Resolution:  D1,720P,960p
Signal Level:  1Vpp
12V power output
Power output: Temporary power output 12V 1A DC
Audio test :  Input audio signal, and played on the internal speaker
Power supply: External power supply : DC 5V(2A)
Battery-powered : Built-in 3.7V li-polymer battery, Capacity 2600mAh
Charge:
Charge time:  3-4 hours Battery power time 8 hours
Power saving features:
Low power consumption, automatic power off, Real-time display of battery level
System settings
Language settings: Chinese, English user selectable
Auto power off : Disable / 5-60 minutes

cable test
Test any two or more wire cable Display connect sequence and remote number
LED Light: 1*35lm LED light
Working environment and Specifications: -20degree---+70degree ; 30%-90% Rh

Package Size: 13.0 * 14.0 * 22.0 ( cm )
Gross Weight/Package: 1.0 ( kg )
