Wide Dynamic Camera with On Screen Display
SPECIFICATIONS |
Model | · | CAM3011 |
TV SYSTEM | · | NTSC/PAL |
IMAGE SENSOR | · | 1/3" color CCD image sensor |
Number of Pixel | · | 811(H) x 508(V) / 795(H) x 596(V) |
Scanning System | · | 525Lines/NTSC, 625Lines/PAL |
Resolution | · | 470 TVL / 580 TVL (Enhanced) |
Minimum illumination | · | 0.4 Lux / F1.2, 0.015Lux/F1.2 5600K |
White Balance | · | ATW/AWB/FIX Switchable (Zero color rolling) |
| | 3200 - 10000K (2200 - 15000K with S Filter |
S/N Ratio | · | 52db (MIN) / 60db(TYP) (AGC off) |
Electronic Shutter | · | 1/60 (1/50) to 1/120,000 sec. |
Auto Iris | · | AEC/DC |
OSD Display | · | On screen display for all control |
5 Push SW | · | For OSD control panel |
Flickerless | · | Selectable by OSD manual |
Mirror Function | · | Selectable by OSD manual |
Up side down | · | Selectable by OSD manual |
BLC Function | · | Selectable by OSD manual |
Image Enhance | · | Selectable by OSD manual |
DIGITAL ZOOM(2X) | · | Selectable by OSD manual |
Negative Image | · | Selectable by OSD manual |
Masking Area | · | Selectable by OSD manual |
Digital Gain Boost | · | Selectable by OSD manual |
Wide Dynamic | · | 48dB(280:1) |
Video Output | · | Composite & Y/C Output 1.0V p-p at 75 Ohm |
GAMMA Correction | · | 0.45 |
Power Source | · | DC12V |
Current Consumption | · | 200mA |
